About Phlexing
Anchored in Advanced-Node Signoff
Empowering a τ-Aware EDA Framework
Phlexing Technology Co., Ltd. ("Phlexing") is a core driver of the τ-Aware design paradigm for the post-Moore era and a provider of full-stack Signoff solutions. Focused on the Signoff stage at advanced process nodes, the company builds upon its self-developed integrated platform to deliver end-to-end capabilities spanning parasitic extraction, timing signoff, power integrity, electro-thermal coupling, and reliability verification. By practicing the Shift Left methodology across the full design flow and implementing DTCO (Design-Technology Co-Optimization), Phlexing systematically resolves critical Signoff challenges, driving the paradigm shift from experience-driven to data-driven chip design and enabling customers to achieve holistic PPA optimization.
Headquartered in Hangzhou, Zhejiang, Phlexing has established five R&D centers in Shanghai, Chengdu, Beijing, Xiamen, and Shenzhen, forming a nationwide R&D and technical-service network. The core team, led by returned scientists, averages over 20 years of industry experience in EDA and high-end chip design.
Phlexing has established deep strategic partnerships with multiple global top-tier chip design companies and foundries. Facing the post-Moore era, we will continue to take independent innovation as our engine, join hands with industry-chain partners to build the domestic EDA ecosystem, and inject core momentum into the high-quality development of China's semiconductor industry.
